ACOUSTIC DOOR

ACOUSTIC WOODEN DOOR
WOODEN ACOUSTIC DOOR: – 55mm to 72mm thick sandwich type composite sound reducing flush door shutters. The combined assembly set of door frame and door shutters to be as per following details:

(a) Door frame shall be of teak / hard wood of size – 110 mm X 100 mm, including making necessary grooves in the frame for fixing of hollow bulb type EDPM gaskets on rebates to block noise leakage from gap in between door frame and shutter.

(b) The frame of shutter shall be made from 40 mm thick teak / hard wood stiles and top & bottom rails of size 94 mm and core made of lock rail 100 mm wide and 40 mm thick and three additional strips 50 mm wide and 25 mm thick (minimum)

(c) The core of door shutter shall be filled with acoustic insulation material , sound absorbing and damping material.

(d) Face panels shall be of 12 mm thick Marine ply boards of approved make conforming to relevant IS codes / International Standards on both sides of the core of the shutter with required primer at the unexposed surface . One side of ply board shall be fixed to the core of the shutter along with a 5 mm thick Neoprene rubber sheet on its inner face.

(e) 01 mm mica OR 04 mm thick Teak Veneer of approved make shall be bonded with 12 mm thick marine plyboard on both face of shutter by using high strength cross linked PVAC based adhesive.

(f) Dropdown Seal: – Excellent quality range of Internal Automatic Dropdown Seal, which are manufactured from high grade quality raw materials. These Internal Automatic Dropdown Seal can be customized as per our precious customers specifications. These Internal Automatic Dropdown Seal are widely known for its durability and quality. Internal Automatic Dropdown Seal can be availed at industrial leading price. Resists sound upto 37db, air, insects, cold smoke, light. Designed for timber (wooden) doors.

(g) Hardware- The door assembly shall be fixed to the door frame with heavy duty stainless steel hardware i.e. Door Lock, SS Bal bearing Hinges , SS door handle ‘D’ type back to back, SS Tower bolt

ACOUSTIC STEEL DOOR
Ecotone Leading Manufacturers of Steel Acoustic door, Door Shutter thickness 65mm to 100mm thick depending upon desired STC rating
Tested form Laboratory for airborne sound as per IS-9901(Part III) – 1981, DIN 52210 part IV – 1984, ISO: 140 ( Part III) – 1995 100mm thick – 44 STC rating

65mm Thick – 36 STC rating

Door Frame made out of MS pipe / ISMC at all three sides door shutter made out of 18 / 16 swg CRCA / GI Sheet, Cavity fill with acoustic insulation material to control noise transmission. Neoprene / EDPM rubber gasket fitted in between frame and door shutter to control noise leakage from gap in between shutter and door frame

Doors fitted with heavy duty Door Hinge, Handle, Locking mechanism etc.

Outer Finish – Powder Coating / PU paint / Spray paint

Uses: – Electrical Rooms, DG Rooms , AHU Rooms , Engine Test Bed , Gallery tec.
